| Specification | Details |
|---|---|
| Suit for | Electricity distribution |
| Shape | Conoid, Multi-pyramidal, Columniform, polygonal or conical |
| Material |
|
| Tolerance of the dimension | ± 2% |
| Power | 10KV ~ 550KV |
| Safety Factor |
|
| Design Load | 300~1000 Kg applied to 50cm from the top pole |
| Marks | Name plate through rivet or glue, engrave, emboss as per customer requirement |
| Surface treatment | Hot dip galvanized following ASTM A123, color polyester powder or any other standard by client required |
| Joint of Poles | Insert mode, inner flange mode, face to face joint mode |
| Design of pole | Against earthquake of 8 grade |
| Wind Speed | 160 Km/Hour (30 m/s) |
| Minimum yield strength | 355 MPa |
| Minimum ultimate tensile strength | 490 MPa |
| Max ultimate tensile strength | 620 MPa |
| Standard | ISO 9001 |
| Length of per section | Within 14m once forming without slip joint |
| Welding |
|
| Thickness | 1 mm to 30 mm |
