We supply customized steel poles to meet specific requirements, with pricing based on weight and specifications. Our professional technical team designs practical, cost-effective solutions while maintaining quality standards.
| Material | Q345, Q235, GR65 |
|---|---|
| Height | 8m, 10m, 11.8m |
| Voltage | 10kv 20kv 50kv, 110kv 138kv 220kv, 500kv |
| Safety Factor | Safety factor for conducting wire: 8 Safety factor for grounding wire: 8 |
| Design Load | 300~1000 Kg applied to 50cm from the top pole |
| Wind Speed | 160 Km/Hour (30 m/s) |
| Length per Section | Within 14m once forming without slip joint |
| Welding | Internal and external double welding with AWS (American Welding Society) D 1.1 standard |
Raw material test → Cutting → Molding/bending → Welding (longitudinal) → Dimension verification → Flange welding → Hole drilling → Calibration → Deburring → Galvanization/powder coating/painting → Recalibration → Threading → Packaging
Our products feature high resistivity against heat, humidity, moisture, and water due to specialized production techniques using rare earth elements. We conduct product damage tests to ensure safety and quality.
| Size | 60cbm |
|---|---|
| Weight | 26000kg |
| Packaging Details | Standard container packaging (L*W*H) with protective mats/straw bales at top/bottom and wooden spacers between poles to prevent galvanization damage. Custom packaging available upon request. |
A: Provide exact dimensions (height, thickness, material, top/bottom diameter) or send a drawing for accurate pricing.
A: Yes, we welcome small wholesalers and grow together with our clients.
A: We support designers in bringing their concepts to reality through our manufacturing capabilities.
A: Submit your business profile and proposal to delia@yin-he.com for consideration.
A: Jiangsu Milky Way Steel Poles Co., Ltd has been manufacturing and exporting steel poles since 1991, serving over 70 countries worldwide.
A: Yes, we provide special support for VIP clients with established brands based on previous sales performance.
A: Yes, we offer comprehensive door-to-door services including customs clearance with competitive shipping rates.
